Waffle Pack/Chip Tray Clip is an accessory that locks the tray and cover together by applying uniform compression along the tray edges. This prevents die movement, offsets lid or tray warpage, and ensures stack stability during handling, shipping, or automated processing.
4-inch Waffle Pack Clip HN25103 and HN25109 are one-piece integral clip that holds chip trays of different thicknesses depending on their height.
Protects die and substrates such as thin film capacitors, shims, RF switches, MMICs, pedestals, etc. from damage when shipped in industry standard waffle pack chip trays.
| Part Number | Tray Size & Funtion | Style | Color | Capacity | Material | Outline Size |
|---|---|---|---|---|---|---|
| HN25103-A | 4" Clip/Clamp | 1 Piece Clip | Black | 2 | PP | 102.67×100.59×6.5mm |
| HN25103-B | 4" Clip/Clamp | 1 Piece Clip | Black | 2 | PP | 102.67×100.59×7.2mm |
| HN25103-C | 4" Clip/Clamp | 1 Piece Clip | Black | 2 | PP | 102.67×100.59×8mm |
| HN25109 | 4" Clip/Clamp | 1 Piece Clip | Black | 6 | PP | 108.84X100.59X27.1mm |
| HN24151#28722 | 4" Clip/Clamp | 2 Pieces Clip | Semi-Transparent | 2 | PP | 58×20.1×19.42mm |
| HN24151#28723 | 4" Clip/Clamp | 2 Pieces Clip | Semi-Transparent | 6 | PP | 58×25.7×19.42mm |
| HN2039 | 4" Clip/Clamp | 2 Pieces Clip | Black | 2 | PP | 106.88×50.8×13.69mm |
| HN2075 | 4" Clip/Clamp | 2 Pieces Clip | Black | 3 | PP | 106.68×50.8×19.81mm |
| HN1957 | 4" Cover/Lip | / | Black / Transparent | N/A | PC | 101.6×101.6×4.5mm |
| HN22070 | 4" Cover/Lip | / | Black | N/A | PC | 101.6×101.6×8mm |
