Reliable wafer shipping solution ensuring protection from contamination and mechanical damage
This vertical flex frame wafer shipper is engineered for the safe transport of wafers mounted on dicing, flex, or film frames. Its precision slot design keeps frames upright and immobilized, while interior contours cradle the frame’s edge to prevent wafer surface contact, avoiding scratches and micro-cracks. A spring mechanism in the upper cover prevents movement, ensuring wafers remain stable during transit. Constructed from high-purity polymer, the shipper minimizes ionic contamination, outgassing, and particle generation. Each unit undergoes dust-free cleaning and Class 100 purification packaging, delivering contamination-free wafer storage and reliable protection for high-value semiconductor wafers during shipment.
• Handling and storage of wafers mounted on flex, film, or dicing frames
• Safe vertical orientation to facilitate easy loading and unloading
• Minimizing mechanical stress during the transportation of fragile wafers
• Protection from environmental contamination in cleanroom logistics
| BASIC INFORMATION | ||
|---|---|---|
| Part Number | Collocation Reference | Wafer Size |
| MVWS-8/25-NP | Bottom+Cassette+Top | 8"/200 mm |
| Metarial | Maximum Capacity | Color |
| Nature PP | 25 | Transparent |
| Delivery Time | Usually 2-3 weeks, depending on order quantity |
* For more sizes or customization needs, please contact our team. We offer one-stop packaging solutions for your products.
| TECHNICAL DATA | ||
|---|---|---|
| PROPERTY | TEST METHOD | RATED VALUES |
| Density | ISO 1183 | 0.9 g/cm³ |
| Melt Index | ISO 1133 | 15 g/10min |
| Melting Point | DSC | 146°C |
| Distortion Temperature | ISO 75 | 95°C |
| Vicat softening temperature | ISO 306 | 125°C |
| Tensile Strength at Yield | ISO 527 | 280 kg/m² |
| Tensile Elongation at Break | ISO 527 | 300 % |
| Rockwell hardness R scale | ISO 2039 | 98 |
| Tensile Strain at Break | ISO 527-2 (50mm/min) | 10 % |
| Flexural Modulus | ISO 178 | 10500 kg/m² |
| Flow Shrinkage | FPC Method | 1.3~1.7 % |
| LZOD Impact Strength | ISO 180/23°C ISO 180/-20°C | 6 kg.cm/cm --- notch |
* The above data are typical laboratory values and are only used as a reference, not as a guarantee for quality indicators or any other use.
