Gel-Box Carriers are designed for manual applications in which devices are loaded using a vacuum pen, tweezers or fingers and unloaded only using tweezers or fingers. Devices are securely held in place when sufficient surface contact is made with the Gel surface. The Gel holding strength is weakest in the peel direction; therefore the devices can be easily removed from the Gel by simply applying a twist or rotation motion. Vacuum pick-up tools typically will not work for unload because a twist or peel motion is required.
The Gel is available in a wide range of tack levels (referred to as Retention Levels) for use with various device types and surface finishes.
Gel-Box are ideal for immobilizing a variety of components during shipping and handling including:
Optics, Semiconductor devices, Medical components, AFM tips, etc.
| Gel Box | |||
|---|---|---|---|
| Part Number | Overall Dimensions | Inner Dimensions | Grid Size |
| HN#5510 | 55×55×10mm | 51×51×6.4mm | 2.5×2.5mm |
| HN#7515 | 75×55×15mm | 71×51×11mm | 5.1×3mm |
| HN#8512 | 85×85×12mm | 81×81×7mm | 5.6×5.6mm |
| HN#12012 | 120×120×12mm | 116×116×8.5mm | 4.5×4.5mm |
| HN#15020 | 150×150×20mm | 146×146×16mm | Blank/Customizable |
| HN19101A | 66.5×91.9×15.7mm | 63.5×88.9×12.7mm | Blank/Customizable |
| HN19101B | 155.4×104.6×15.7mm | 152.4×101.6×12.7mm | 10.49×6.5mm |
| Remark | |||
| Viscidity： Low, medium, and high optional Color： Top&Botom: Transparent | Top: Transparent, Bottom: Black | Top&Botom: Black(ESD) |
