Precision-molded cassette ensuring accurate wafer alignment and maximum cleanliness
Wafer cassettes are used to transport and store wafers during semiconductor manufacturing operations. For the general process, wafer cassette is engineered for in-fab transfer and temporary storage of wafers between process stations. Also referred to as wafer boats, they are designed to house or carry several wafers of the same size and are available in a range of materials to support specific applications, such as thermal processing. This wafer cassette is molded from polypropylene, they tolerate typical fab temperatures and are available in natural or conductive material. These wafer cassettes, designed for advanced wafer transport, provide precise wafer access, reliable equipment operation, and secure wafer protection, address automation, contamination control, and productivity requirements for today's fabs. It can collocation with wafer storage boxes to protect wafers.
• Holding and organizing wafers during cleaning, drying, and inspection
• Transport of wafers between cleanroom processes
• Storage of wafers in standard fab equipment racks
• Cost-effective solution for general wafer handling needs
| BASIC INFORMATION | ||
|---|---|---|
| Part Number | Collocation Reference | Wafer Size |
| MCS-8/25-NP | -- | 8"/200 mm |
| Metarial | Maximum Capacity | Color |
| PP | 25 | Transparent |
| Delivery Time | Usually 2-3 weeks, depending on order quantity |
* For more sizes or customization needs, please contact our team. We offer one-stop packaging solutions for your products.
| TECHNICAL DATA | ||
|---|---|---|
| PROPERTY | TEST METHOD | RATED VALUES |
| Density | ISO 1183 | 0.9 g/cm³ |
| Melt Index | ISO 1133 | 15 g/10min |
| Melting Point | DSC | 146°C |
| Distortion Temperature | ISO 75 | 95°C |
| Vicat softening temperature | ISO 306 | 125°C |
| Tensile Strength at Yield | ISO 527 | 280 kg/m² |
| Tensile Elongation at Break | ISO 527 | 300 % |
| Rockwell hardness R scale | ISO 2039 | 98 |
| Tensile Strain at Break | ISO 527-2 (50mm/min) | 10 % |
| Flexural Modulus | ISO 178 | 10500 kg/m² |
| Flow Shrinkage | FPC Method | 1.3~1.7 % |
| LZOD Impact Strength | ISO 180/23°C ISO 180/-20°C | 6 kg.cm/cm --- notch |
* The above data are typical laboratory values and are only used as a reference, not as a guarantee for quality indicators or any other use.
